MasterCut

MasterCut

Mastercut is a versatile CNC cutting machine which can be applied throughout the industry reaching from small workshops to big factories. The application range of the entry version with rails in X direction dedicated to fully automated oxyfuel cutting or cutting with conventional plasma can be enhanced to a variety of high precision plasma cutting applications including pipe, profile or elbow cutting and marking.

Technical parameters

Working length 3000 – 30000 mm
Working width1500 – 4000 mm
Max. number of tool stations 4 (6G)
Max. thickness of material cut by plasmaaccording to a plasma source
Max. thickness of material cut by oxyfuel150 mm (optionally 200 mm )
Positioning speedup to 30 m/min (depends on version)
Positioning accuracy± 0,12 (depends on version) according to DIN 28 206
